Pcba Manufacturer Custom Electronic Circuit Board Turnkey Service Multilayer Prototype PCB Assembly
PCB Capability
| Article | Description | Capability |
| Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Max Size of Finish Board | 700*460mm |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
Delivery Time for PCBA
| Order Conditions | Standard Delivery Date | The fastest Delivery Date |
| Prototype (<20 pcs) | 2 days | 8 hours |
| Small Volum (20-100 pcs) | 3 days | 12 hours |
| Medium Volum(100-1000 pcs) | 6 days | 24 hours |
| Mass productions (>1000 pcs) | Depends on BOM | Depends on BOM |
FASTPCBA is the best choice for high quality pursuit customers of medical pcba, automotive pcba, industry pcba, communication pcba, military pcba, aerospace pcba etc.
FASTPCBA can be called a “revised type pcba assembly factory”, who can provided free value added pcba files modification service and turn your pcb design to the most highest quality pcb fabrication and assembly products, as we have engineer teams average pcba industry experience over 20 years to optimize the customer's pcb design but keep the use function at the same time.
FASTPCBA continuously imported advanced pcb machine from Gemany, America, Japan, ERP control pcb process, with complete dust free and esd protection smt workshop, high quality medical pcba, aerospace pcba, automotive pcba, industrial control pcba, smart home pcba, power communication pcba, military pcba all out of FASTPCBA.
As a IATF & ISO certificate pcb assembly manufacturer, FASTPCBA is busy 24/7/365 with pcba orders for over 50 countries 2000 customers. High pcb capacibility ensure punctual pcba delivery all the time, welcome to place pcba order on us.
